ARCCAPTAIN PLASMA CUTTER CUT50 Dual Voltage Portable HF Start Cutter CUT50

The ArcCaptain CUT50 is a portable 50-amp plasma cutter with dual-voltage input (110V/220V), so it can run on shop or job-site power. The pilot arc start cuts through painted, rusty and rough surfaces, and it cuts mild steel, stainless steel, alloy steel, copper and aluminum faster and cleaner than a grinder or oxy-fuel torch, with less heat distortion. A large LED display makes settings easy to read, and the adjustable post-flow (5-15 seconds) helps extend the life of torch consumables. At 5.8 kg (about 13 lb) with a shoulder strap, it is easy to carry between jobs. Typical uses: sheet metal fabrication, automotive work, farm and equipment repair, HVAC, and general maintenance.

KEY FEATURES

• 50-Amp Output, 60% Duty Cycle - Output current range of 20-50 A on 220V (20-35 A on 110V).
• Dual Voltage - Runs on 110V or 220V input power.
• Pilot Arc Start (HF Touch) - Non-touch arc starting that cuts painted, rusted and uneven surfaces.
• Serious Cutting Capacity - Clean cuts up to 1/2 in. (12 mm) on 220V, with a maximum severance cut of about 11/16 in. (18 mm).
• Large LED Display - Read output and settings clearly, even with your helmet on.
• PT31 Torch with 16 ft Lead - Room to move around the workpiece without repositioning the machine.

Technical specifications

• Type: Inverter plasma cutter
• Processes: Plasma cutting
• Output current: 20-50 A (220V) / 20-35 A (110V)
• Duty cycle: 60%
• Input voltage: 110V/220V dual voltage
• Max clean cut: 1/2 in. (12 mm) at 220V
• Max severance cut: approx. 11/16 in. (18 mm) at 220V
• Arc start: Pilot arc (HF touch)
• Post-flow: adjustable 5-15 seconds
• Torch: PT31 cutting torch, 16 ft lead
• Air supply required: air compressor, 90 PSI or more, 5 CFM or more, 10 gal tank or larger recommended
• Materials: mild steel, stainless steel, alloy steel, copper, aluminum
• Weight: 5.8 kg (12.8 lb)
